Radiata Pine Plywood & Siding
Putnam Lumber ships full container loads of Radiata pine plywood & siding from Chile directly to our clients. The exterior plywood & siding is a product manufactured with rotary cut layers of pine bonded with phenolic adhesive. The face of the panel is repaired and sanded smooth. The direction of the fiber in one layer is perpendicular to the direction of the fiber in the upper and lower layers, making it more resistant than solid wood. The plywood is certified and complies with structural functions.
Pressure Treated Plywood & Siding
Exterior plywood & siding can be ordered untreated or pressure treated. The treatment chemical used is MCA, which is manufactured in the USA and is the same chemical used for exterior applications in the US domestic market. After the panel is treated, it is carefully stacked with spacers between each panel and placed in a kiln for drying after treatment (KDAT). This drying process is an extra step that returns the moisture content to the same level prior to treatment and improves the performance of the panel on the jobsite.
Export Packaging
Siding is carefully packaged for transport in container with minimal damage. All four sides of the bundle are covered to protect the entire bundle during loading, ocean transit, and unloading.
Adhesives
Formaldehyde-Phenol Resins are used as adhesive, which comply with the OUTDOOR category (Water and Boil Proof) of European standard EN 314-1/2:1993. The adhesive is capable of withstanding the most severe conditions of exposure in environments with a high level of humidity without deteriorating.
Certification
All grade marked panels are produced and edge stamped as per the US Department of Commerce Voluntary Product Standard PS 1-09, Structural Plywood in compliance with ISO/IEC Standard 17020 and 17025 accredited through IAS. The certification programs are accredited by ANSI for ISO/IEC 17065. The manufacturer has satisfied the requirements for certification outlined in the TP Inspection Procedure - Structural-use Panels.
Premium Grade Radiata Pine Plywood Siding
T1-11 Groove Decorative Siding is manufactured with foliated veneers and bonded with phenolic adhesives. Manufactured according to PS 1-09 standards, Premium grade face veneer with no more than 6 wood patches and no synthetic repairs. Pre-sanded and ready to apply finish. Ideal for paneling, walls, and ceilings with a quick and simple installation, perfect fit due to its tongue and groove shiplap system.
Grooving Options
T1-11 Siding can be grooved with 2 inch, 4 inch, or 8 inch on-center grooves.
Nominal Imperial |
Actual Imperial |
Actual Metric |
Number of Plies |
Standard Pack Sizes |
---|---|---|---|---|
3/8" 4'x8' 1/2" 4'x8' 5/8" 4'x8' 3/4" 4'x8' |
11/32" 4'x8' 15/32" 4'x8' 9/16" 4'x8' 23/32" 4'x8' |
9 mm 1.22x2.44 m 12 mm 1.22x2.44 m 14 mm 1.22x2.44 m 18 mm 1.22x2.44 m |
5 5 5 7 |
108 pieces 80 pieces 70 pieces 55 pieces |
Premium Grade Radiata Pine Beaded Plywood
Beaded Decorative Plywood is manufactured with foliated veneers and bonded with phenolic adhesives. Manufactured according to PS 1-09 standards, Premium grade face veneer with no more than 6 wood patches and no synthetic repairs. Pre-sanded and ready to apply finish. Ideal for paneling and ceilings with a quick and simple installation, perfect fit due to its shiplap edge groove system.
Grooving Options
Beaded Plywood can be grooved with 1.6 inch, 2 inch, or 3.5 inch on-center beaded grooves.
Nominal Imperial |
Actual Imperial |
Actual Metric |
Number of Plies |
Standard Pack Sizes |
---|---|---|---|---|
5/32" 4'x8' 1/4" 4'x8' 3/8" 4'x8' |
5/32" 4'x8' 7.6/32" 4'x8' 11/32" 4'x8' |
4 mm 1.22x2.44 m 6 mm 1.22x2.44 m 9 mm 1.22x2.44 m |
3 3 5 |
248 pieces 150 pieces 108 pieces |
BCX Sanded Radiata Pine Plywood
BCX plywood is a beautiful pine panel where a strong, beautiful, and smooth panel is needed. Manufactured according to PS 1-09 standards. Easy to work with conventional wood tools. Its internal structure has more solidity and mechanical resistance, superior dimensional stability, low moisture absorption, minimal swelling, and high tolerance to the corrosive action of weather.
Nominal Imperial |
Actual Imperial |
Actual Metric |
Number of Plies |
Standard Pack Sizes |
---|---|---|---|---|
5/32" 4'x8' 6/32" 4'x8' 7/32" 4'x8' 1/4" 4'x8' 3/8" 4'x8' 1/2" 4'x8' 5/8" 4'x8' 3/4" 4'x8' |
5/32" 4'x8' 6.6/32" 4'x8' 7/32" 4'x8' 1/4" 4'x8' 11/32" 4'x8' 15/32" 4'x8' 19/32" 4'x8' 23/32" 4'x8' |
4 mm 1.22x2.44 m 4.8 mm 1.22x2.44 m 5.2 mm 1.22x2.44 m 6 mm 1.22x2.44 m 9 mm 1.22x2.44 m 12 mm 1.22x2.44 m 15 mm 1.22x2.44 m 18 mm 1.22x2.44 m |
3 3 3 3 5 5 7 7 |
240 pieces 195 pieces 180 pieces 150 pieces 108 pieces 80 pieces 63 pieces 55 pieces |
